HDPE Monofilament Rope


Divine Industries coming with widest range of 3 Strand & 4 Strand Ropes made from High Density Poly Ethylene Monofilament Yarn (HDPE), Poly Propylene Monofilament Yarn (PPMF) & Poly Propylene Danline Yarn (PPD) for different applications such as Fishing, Shipping, Ports, Shipbuilding Yards, Stevedoring, Defence, Material Handling, Construction, Electricity Boards and various other Industrial Applications.

Characteristics:

  • Resistance to abrasion | Shock loading
  • Smooth finish | Easy to handle
  • Same breaking strength in dry or wet conditions
  • Same breaking strength in dry or wet conditions

Specifications (3 Strand) :

SIZE WEIGHT Minimum
Breaking
Strength
Dia (mm) Dia (inch) kg/100m kgf of tons KGF
4 5/32 0.727 200
5 3/16 1.136 290
6 7/32 1.636 400
7 1/4 2.227 550
8 5/16 2.909 700
9 11/32 3.681 900
10 3/8 4.545 1090
12 1/2 6.545 1540
14 9/16 8.909 2090
16 5/8 11.636 2800
18 3/4 14.727 3500
20 13/16 18.181 4300
22 7/8 22 5100
24 1 26.181 6100
26 1 1/16 30.727
28 1 1/8 35.636
30 1 1/4 40.909
32 1 5/16 46.545
34 1 3/8 52.545
36 1 7/16 58.909

4 Strand ropes are available from 6 mm dia onwards
  • Tolerance: Up to 14 mm = + /– 8% » 16mm & above = + /– 5%
  • Std Packing: PE ropes are generally packed individually in plastic bags and then coils are packed in woven bags for shipping.
  • Coil Lengths: These ropes are available in 100/200/300 mtrs or yards or 300 / 600 / 1200 ft. (Long lengths are available on request.)
  • Colours: Yellow, Blue, Red, Green, Orange, White, Black. Brown.


Applications

  • Commercial
  • Marine & Fishing
  • DomesticsDomestics



  • Commercial
  • Marine & Fishing
  • DomesticsDomestics
Notes
  • The minimum breaking load (MBL) should never be considered as the safe working load of the rope.
  • Breaking strength quoted relates to the new dry ropes in soft lay construction. In wet conditions these values may be lower.
  • Same breaking strength in dry or wet conditions
  • Please contact us for information regarding long lengths, special colours and different packing.
